Parameters:

• Processing Speed: 64 MHz
• Data Type: 32-Bit Floating Point
• Memory: 1 Megabyte
• Operating Frequency: 64 MHz
• Clock Accuracy: 3.5 seconds per day (max)
• Internal Timing Accuracy: 0.01% (max)

Specifications:

• System Compatibility: IC66* Triple Modular Redundancy Systems
• Battery-Backed Memory: 1 Mbyte in the same slot
• Discrete Inputs/Outputs: Up to 12K
• Communication Ports: Single RS422/485 Port
• Voltage Rating (5V Bus): 3.3 Amps
• Operating Temperature Range: 0 to 60°C (32 to 140°F) with forced air cooling, 0 to 40°C (32 to 104°F) without

Dimensions and Weight:

• Weight: 4.00 lbs

Series:

• GE Fanuc Series 90-70 CPU

Features:

• High-Performance: 64 MHz, 32-bit floating-point processing unit for efficient and fast computations.
• Flexible Memory: 1 Megabyte of battery-backed memory for data retention during power outages.
• Communication Capability: RS422/485 port for connecting to other machines and systems.
• Wide Operating Range: Suitable for various environmental conditions.
• Reliable: Designed for stability and durability in industrial environments.

Applications:

• GE IC697CPM790 is used in various industrial automation systems, such as power, energy, chemicals, pharmaceuticals, and food processing, to improve production efficiency and control precision¹
