Specifications :
Output range: The analog output range of DSQC209 can be selected from 0 ~ 20mA, 4 ~ 20mA, 0 ~ 5V, 0 ~ 10V (each channel can only be selected one).
Input range: Analog input range includes -10 ~+ 10V, 4~+20mA, thermal resistance (each channel can only select one).
Digital input: 5 channels.
Digital output: 7 channels.
Communication port: Dual communication port, RS232 and RS485 respectively
function :
The DSQC209R is a flexible PLC that can be modified and reduced according to user requirements for different applications.
It provides both analog and digital inputs and outputs for industrial environments that require precise control and monitoring.
parameter :
Rated voltage: AC85~265V.
Power consumption: 5V/0.55A, 24V/0.2A.
Instantaneous power off time: within 10ms(AC or DC).
Insulation impedance: above 5MΩ (DC500V).
Anti-interference: peak 2000Vp-p; Frequency 5KHz; Rise time 5ns; Pulse width 50ns.
Ambient temperature: operating 0℃ ~55℃; Store -25℃ ~70℃.
Analog output resolution: 12 bits.
Analog output accuracy: ± 0.2% FSR (full scale range).
Size :
Size: 84×111×82 (unit: mm)
