05704-A-0144 Out of production spare parts

05704-A-0144 Out of production spare parts You take a small step to open an inquiry, and I will return a big step to your success. You only look at our prices, but you don’t see our quality. Others have imitations of others’ gau, and we have some genuine products. Our products and services can support a team and company. In the current market, there are too many dazzling products. Only the real quality is the magic weapon to win. Quality is equal to trust, and trust is equal to wealth. Having your trust is my great wealth. Please don’t hesitate, don’t get lost, and call quickly! Contact: 15340683922 Only one person is willing to inquire and cooperate for a long time I don’t want you to Zhengda promises: 1. Guarantee new and original import 2. Ensure on-time delivery 3. Guarantee the quality of after-sales service

Description

Estimated Lead Time: 6 – 8 weeks.

Manufacturer: Honeywell

Product No.: 05704-A-0144

Product type: Four Channel Control Card Catalytic Input

Power Consumption: 12.8W (maximum at 200mA sensor current). 8.5W (typical).

Drive: Constant Current.

Initial Accuracy: ±1%.

Current Adjustment: Electronic in 1mA stepsfrom 90 to 315mA.

Maximum Drive Voltage: 10V

Protection: Protected against short circuit and open circuit.

Maximum Line Resistance: 40 ohms (including sensor) at 200mA.

Full Scale Signal Range: 15mV to 300mV

Bridge Imbalance Default Limits: ±100mV from centre at 2V bridge voltage.

Adjustment: Electronic adjustment of bridge balance and signal gain.

Fault Detection: Open circuit. Short circuit single bead failure.

Shipping weight: 2 Kg

05704-A-0144
