1394C-SJT22-A servo controller
1394C-SJT22-A is an
Allen-Bradley servo controller
with analog module functionality and a ±10 Volts DC analog interface. It is a Series C system module with features such as Smart Power, EMI filtering, and improved terminations. The
1394C-SJT22-A system can support up to four axes and work as a velocity or torque controller. It comes with the Bulletin 1201 Human-Machine Interface Module which allows automatic tuning and quick start-up. This 1394C-SJT22-A also has a SCANport interface
, a continuous output current of 33.8 Amps with DC voltage, a continuous output power of 22 kW
, and a three-phase power supply. The 1394C-SJT22-A has power inputs such as 24 Volts AC power, a disconnect function, a fuse block, and a 24 Volts DC power supply for motor brakes and thermal contacts.
