ABB DSMB127 57360001-HG

Product Features Expected lead time: 1-3 days ① Brand: ABB ② Model: DSMB127 57360001-HG ③ Product category: Module ④ Payment method: T/T, USD, Western Union ⑤ Freight: The freight for different regions will be borne by the local freight forwarder. ⑥ Does it include tariffs? It does not include any taxes. ⑦ Packaging: Use the seller’s safe packaging.

Category: ABB

Description

Product Name

ABB DSMB127 57360001-HG

Product Description

The ABB DSMB127 57360001-HG is a digital input/output module that is designed to be used in a variety of industrial applications. It features 16 digital inputs and 16 digital outputs that can be controlled and monitored via a variety of communication protocols.

Product Parameters

Model Number: DSMB127 57360001-HG
Number of Inputs: 16
Number of Outputs: 16
Communication Protocols: Modbus RTU, Profibus DP, DeviceNet, ControlNet, EtherNet/IP
Power Supply: 24V DC
Operating Temperature: -20°C to +70°C
Dimensions (HxWxD): 120mm x 70mm x 85mm
Weight: 0.3kg

Specifications

Input Voltage: 24V DC
Input Signal Voltage Range: 0-30V DC
Input Signal Current Range: 0-20mA
Input Response Time: 0.1ms
Output Voltage: 24V DC
Output Current: 0.5A per channel, 8A maximum per module
Output Response Time: 0.5ms
Output Short-Circuit Protection: Yes
Isolation Voltage: 500V AC
Isolation Resistance: 1MΩ
LED Indicators: Power, Communication, Input/Output Status
