The DS200TCTGG1AFF is a simplex trip board that is part of the GE Speedtronic Mark V gas turbine control system. Simplex trip boards are used as intermediate trip boards. There are 21 plug-in relays on simplex trip board DS200TCTGG1AFF. The board also includes three 50 pin connectors and two 12 pin connectors. JLY, JLX, and JLZ are the IDs assigned to the 50 pin connector. JN and JM are the IDs assigned to the 12 pin connector. The ID of 21 plug-in relays starts with K and ends with a number.
The numbers are listed in ascending order, starting with 1. K1, K5, K10 and K21 are some IDs. When the relay is stuck on the circuit board, the metal strip fixes the relay in place. Detach the metal strip from the relay and remove it by pulling it out of the connector.
Align the relay with the connector and press it into the connector for installation. Then, clamp one end of the metal strip on the connector, arrange the metal wire on the top of the relay, and clamp the other end of the metal wire to the other side of the connector.
WOC has the largest stock of Speedtronic Mark V control spare parts. We can repair your DS200TCTGG1AFF with a warranty period of 12 months.
WORLD OF CONTROLS can also provide unused and rebuilt DS200TCTGG1AFF with a warranty period of 24 months. Our expert team supports you 24 hours a day to meet your DS200TCTGG1AFF needs.
