Description
parameter :
Memory size: 16 MB SDRAM, 32 MB flash 1.
Input voltage (redundant voltage): 24 V DC typical value 1.
Power consumption: Maximum 8.5W1 per non-fault-tolerant module.
Operating temperature: 0 to +60 degrees Celsius (+32 to +140 degrees Fahrenheit) 1.
Specifications :
Type: Field Control Processor 270 (FCP270) 1.
Configuration: Single-processor module, fault-tolerant by two processor modules, the substrate integrated into an interconnect fault-tolerant connector
Size :
Dimensions (L x W x H): 14.7cm x 5.15cm x 11.4cm 1. It is also stated that the size specification is 23cm (may refer to the length in a particular direction)
Weight :
Weight: 0.6 kg
Shipping weight: 1.5 kg
series :
This product belongs to the FCP series, the specific model is FCP270 P0917YZ14.
Features :
Modular design, allowing flexible configuration7.
High compatibility and programmability, support for multiple programming languages 7.
Real-time operation capability and powerful communication function, support a variety of communication interfaces 7.
High reliability and stability for industrial environments 6.
function :
Used in industrial automation and process control systems to monitor and control various process variables and equipment such as temperature, pressure, flow, valves, motors, etc. 6.
Achieve regulation, logic, timing and sequence control to improve production efficiency and system stability
