Description
Product Overview
The GE IC697PWR710F is a robust and reliable power supply module designed for the GE Fanuc Series 90-70 Programmable Logic Controller (PLC) system. This critical component serves as the primary source of conditioned DC power for the entire PLC rack, converting incoming AC line voltage into the stable and regulated +5V DC power required by the CPU, communication modules, and all installed I/O modules. The reliable operation of the entire control system is fundamentally dependent on the performance and stability of the . It is engineered to deliver consistent power in industrial environments characterized by electrical noise and voltage fluctuations.
Detailed Product Parameters
- Module Type: AC Input Power Supply Module
- Compatible System: GE Series 90-70 PLC
- Input Voltage: 120/230 V AC, 50/60 Hz (user-selectable via a voltage selector switch).
- Output Voltage: +5.1 V DC (regulated for logic and module electronics).
- Output Current Rating: 10 Amps continuous at +5.1V DC.
- Power Rating: 51 Watts.
- Mounting: Installs in the left-most slot (Slot 1) of a Series 90-70 rack (e.g., IC697CHS781). It occupies one slot space.
- Protections: Features built-in overload and short-circuit protection.
- Diagnostics: Includes a green “AC OK” LED and a red “Fault” LED for status indication.
Key Features and Advantages
The GE IC697PWR710F offers significant advantages for system stability and longevity. Its high 10-amp current rating provides ample power to support a fully loaded 90-70 rack with a CPU, communication cards, and numerous I/O modules, ensuring reliable operation even at maximum load. The user-selectable input voltage (120/230V AC) offers flexibility for installation in different geographical regions without needing a different power supply model. Its robust design includes effective filtering to suppress line-borne electrical noise, protecting sensitive digital electronics in the rack. As a genuine GE OEM component, the GE IC697PWR710F guarantees perfect mechanical fit, thermal performance, and electrical compatibility with the 90-70 backplane, preventing potential issues related to connector mismatches or insufficient current capacity that can arise with inferior substitutes.
Application Examples in Key Industries
This power supply is a fundamental component in a vast installed base of Series 90-70 systems across heavy industries:
- Automotive Manufacturing: Powering control racks for large transfer lines, robotic welding cells, and paint shop automation systems.
- Water and Wastewater Treatment: Supplying power to the main PLC rack controlling plant-wide processes like filtration, chemical dosing, and pump station management.
- Material Handling & Distribution: Used in control panels for automated storage and retrieval systems (ASRS), parcel sortation systems, and large conveyor networks.
- Metals and Mining: Providing reliable power to PLC systems controlling rolling mills, crushers, and mineral processing plants.
Comparison with Competing Products
Competing products include third-party power supplies and refurbished units. The genuine holds distinct advantages over generic alternatives. Universal power supplies may not have the specific form factor, the correct high-current backplane connector, or the precise voltage regulation and dynamic response required by the 90-70 system. The GE-original supply is designed to handle the inrush current of multiple modules powering up simultaneously and maintains voltage stability during rapid load changes. While a third-party unit might be cheaper initially, it risks causing intermittent system faults, module resets, or premature failure, which can lead to costly production downtime. For legacy 90-70 systems, the GE IC697PWR710F is the definitive choice for maintaining OEM-level reliability and system integrity.
Selection Guidelines and Important Notes
- Selection Advice: Select the GE IC697PWR710F for any Series 90-70 system requiring a 120/230V AC power source. Before installation, calculate the total +5V DC current draw of all modules in the rack (check each module’s datasheet) to ensure it does not exceed the 10-amp rating. The power supply must be installed in Slot 1 of the rack.
- Installation Precautions: Crucially, set the voltage selector switch to the correct input voltage (120V or 230V) before applying power. Incorrect setting will damage the unit. Ensure all AC wiring is done according to local electrical codes and that the unit is properly grounded. Always disconnect AC power before installing or removing the module.
