Description
Estimated Lead Time: 1-3 days
Manufacturer: HIMA
Product No.: F 3330
Product type: 8 fold Output module, safety related
resistive load or inductive load up to 500 mA (12 W), lamp connection up to 4 W, with integrated safety shutdown, with safe isolation, no output signal with break of the L- supply requirement class AK 1 … 6
Outputs 500 mA, k short circuit proof
Internal voltage drop max.: 2 V at 500 mA load
Admissible line resistance (in + out): max. 11 Ohm
Undervoltage tripping: at = 16 V
Space requirement: 4 TE
Operating data: 5 V DC =110 mA, 24 V DC = 180 mA in add. load
Shipping weight: 5 Kg
F3330
