Description
Technical Specifications for IC698CPE030 Brand GE Fanuc Series PACSystem RX7i Manufacturer GE Fanuc Part Number IC698CPE030 Product Description Central Processing Unit Description Rx7i PACsystem CPU Communication ports Two (2) Ethernet communication ports; One (1) RS232 port; One (1) RS485 port and One (1) Station manager port Application Rx7i PLC System Random Access Memory (RAM) 64 MB Operating Voltage +5, +15, -12 Volt DC Flash Memory 64 MB Current Rating 3.4 Amps Discrete I/O memory 32 K Microprocessor 600 MHz Pentium M Analog I/O memory 32 Kwords CPU Memory 64 Megabytes Compatible Memory storage SRAM, Flash User Memory 64 Megabytes Processor speed 600 MHz Max Program Block 512 Program Blocks Processor type Pentium M microprocessor Supported Operation Floating Point Maths Floating point Supported Programming Languages C, Ladder Diagram, Structured Text, and Function Block Diagram Ethernet data rate 10Mb/sec and 100Mb/sec Built-in Ports 2 Serial (RS-232, RS-485) 1 Ethernet (Auto 10/100, RJ45) FTP / Webserver Supported; Up to 16 connections Supported Protocols Ethernet: SRTP, Modbus TCP Server and Client, Ethernet Global Data (EGD); Serial: Modbus RTU Slave, SNP, Serial I/O. Configuration Proficy Machine Edition Logic Developer PLC version 4.0 or later Location Rx7i Rack
IC698CPE030
