Description
-
Manufacturer: ICS Triplex
-
Product No.: T8431
-
System Supply Voltage Range: 20 to 32V dc
-
Number of Inputs: 40 Channels
-
User Defined Thresholds: 4-off
-
Input Current Range: 0-22mA
-
Input Voltage Range: 0-6 Vdc
-
Sample Update Time: 0.5ms
-
Resolution: 3.9uA (1/256mA)
-
Safety Accuracy: +/- 1% of full scale
(default threshold above which 0x70nn series slice discrepancy faults are raised)
-
Calibration Accuracy: 0.03%
-
Recommended input channel calibration check
-
interval: 2 years
-
Circuit Type: Fault tolerant, fully triplicated with optional line monitoring
-
Fusing: None, external if required
Intrinsic Safety External barrier
Sequence of Events
-
Event Resolution: 1ms
-
Time-stamp Accuracy: ±0.5 ms
-
Field Common Isolation
-
Sustained Working: ±250V dc
-
Maximum Withstanding: ±2.5kV dc
-
Channel to Channel Crosstalk: -40 to –60 dB
-
Power Consumption: 15 – 18W
-
Self-Test Interval: 2 minutes
-
Operating Temperature: -5°C to 60°C (23°F to 140°F)
-
Non-operating Temperature: -25°C to 70°C (-13°F to 158°F)
-
Temperature change: 0.5ºC/min
-
Operating Humidity: 10 – 95% RH non-condensing
-
Environmental Specifications: Refer to Document 552517
-
Dimensions
Height: 266mm (10.5ins)
Width: 31mm (1.2ins)
Depth: 303mm (12ins)
-
Weight: 1.149kg (2.5lbs)
-
Real Time Clock Resolution: 100µSec
-
Shipping Weight: 2 Kg
