Description
Power Specifications LocalBus power rating 12 VDC at 300 mA Field circuit rating 32 VDC at 12 mA/port Environmental Specifications Ambient Temperature -40 to 70o C Shock 10g ½ Sinewave for 11 msec Vibration 1mm Peak to Peak from 5 to 16Hz; 0.5g from 16 to 150Hz Airborne Contaminants ISA-S71.04 –1985 Airborne Contaminants Class G3 Relative Humidity 5 to 95% Non-Condensing IP 20 Rating Terminal block key position D6 Note: Refer to the product label for serial number and location and date of manufacture. Warning: This product has specific instructions for installation, removal and operation in hazardous areas. Refer to document 12P5404 “DeltaV SSeries Digital Automation System Zone 2 Installation Instructions”. Other installation instructions are available in the “DeltaV S-series and CHARMs
KJ3242X1-BK1 12P4711X052
