Description
PPC322BE HIEE300900R1
Modularity, allowing for step-by-step expansion.
• Simple DIN-rail attachment/detachment procedures, using a unique slide and
lock mechanism. PPC322BE HIEE300900R1
• Fast, simple troubleshooting procedures available via unit/channel LEDs.
• IP20 Class protection with no requirement for enclosures.
• Allows for the use of low-cost, sealed enclosures due to extremely low unit
heat dissipation, even at an ambient temperature of 40 C (104 F) outside thePPC322BE HIEE300900R1
enclosure. PPC322BE HIEE300900R1
• All units are fully EMC certified.PPC322BE HIEE300900R1
• Connection of up to 192 I/O signals, via Electrical ModuleBus, is available.
• Connection of up to 1344 I/O signals, via Optical ModuleBus, is available.
• Connection of S100 I/O is available.
• Connection of Satt I/O is available.
• Allows connecting a large number of I/Os, via PROFIBUS DP.
• Connection to FOUNDATION Fieldbus High Speed Ethernet (FF HSE).
• Connection to Modbus TCP.PPC322BE HIEE300900R1
• Connection to IEC 61850.PPC322BE HIEE300900R1
• Connection to Advant Fieldbus 100.
• Connection to MOD5.PPC322BE HIEE300900R1
• Connection to PROFINET IO.PPC322BE HIEE300900R1
• Connection to EtherNet/IP.PPC322BE HIEE300900R1
• Allows connecting custom protocols of a large amount of Serial
communication RS-232C ports.PPC322BE HIEE300900R1
• Connection to MasterBus 300 Networks.PPC322BE HIEE300900R1
• Connection to INSUM via Gateway (Ethernet/LON).PPC322BE HIEE300900R1
• Connection to ABB Drives is available, over DriveBus and ModuleBus.
PPC322BE HIEE300900R1
