Description
3704E TRICONEX 3704E MODULE 7400125-110 3704E Voltage 0-5V or 0-10V1, + 6% Type TMR, AI No. of Input Points 64, commoned Isolated Points No Input Update Rate 75 ms Resolution 12 bits Accuracy < 0.25% of FSR from 0° to 60°C Input Resistance (load) 30 MΩ (DC), min Power-Off Resistance 30 kΩ (DC), typical Common Mode Rejection n/a Common Mode Range n/a Leg-to-Leg Isolation 200 kΩ, typical Normal Mode Rejection -1 dB @ 8Hz -12 dB @ 60Hz -18 dB @ 120Hz Input Overrange Protection 150 VDC/115 VAC continuous Current Range 0-20 mA, 250Ω shunt for 5V 500Ω shunt for 10V Diagnostic Indicators PASS, FAULT, ACTIVE Module Status Color Code Copper
TRICON 3006
TRICONEX 3704E
