The National Instruments SCXI – 1104C is a high – performance data acquisition module designed for industrial control systems3. It is a 32 – differential – channel voltage input module, which is used to condition higher voltage signals1. The SCXI – 1104C comes with a 10 kHz cut – off frequency filter, which can effectively filter out high – frequency noise and ensure the accuracy of the acquired signals1. This module is compatible with the NI SCXI platform, allowing for easy integration with other SCXI modules, thus providing a compact modular solution for control and monitoring functions in industrial environments2.

Category:

Description

NI SCXI-1104C

Product Description

The National Instruments SCXI – 1104C is a high – performance data acquisition module designed for industrial control systems3. It is a 32 – differential – channel voltage input module, which is used to condition higher voltage signals1. The – 1104C comes with a 10 kHz cut – off frequency filter, which can effectively filter out high – frequency noise and ensure the accuracy of the acquired signals1. This module is compatible with the NI SCXI platform, allowing for easy integration with other modules, thus providing a compact modular solution for control and monitoring functions in industrial environments2.

Product Parameters

  • Input Channels: 32 differential channels
  • Input Coupling: DC
  • Cut – off Frequency: 10 kHz
  • Input Voltage Range: ±60 VDC
  • Connector Type: 50 – pin male ribbon cable back connector and 96 – pin male din c front connector
  • Operating Voltage: 220 V
  • Output Frequency: 50 kHz
  • Compatibility: Compatible with NI – DAQ version 6.5.1 or higher, and requires an application development environment such as LabVIEW, Bridgeview, LabWindows/CVI, Visual Basic (ComponentWorks), C, C++, Virtual Bench, or Measure1.

Advantages and Characteristics

  • High Precision: It has high – precision measurement capabilities, which can accurately acquire, process, and analyze digital signals. For example, in some industrial automation scenarios that require precise measurement of voltage signals, the SCXI – 1104C can provide very accurate measurement results2.
  • Strong Compatibility: It is compatible with the NI SCXI platform and can be easily integrated with other modules, which provides convenience for system expansion and upgrading. In an industrial control system that uses the NI SCXI platform, the – 1104C can be quickly integrated into the existing system without major modifications2.
  • Excellent Noise Rejection: With a 10 kHz cut – off frequency filter, it can effectively suppress high – frequency noise and improve the signal – to – noise ratio of the acquired signals. In a noisy industrial environment, this feature can ensure the accuracy and reliability of the data.

Application Areas and Application Cases

  • Applicable Industries and Scenarios: The – 1104C is widely used in industries such as manufacturing, energy, and automation control. It can be used in industrial automation production lines to monitor and control the voltage signals of various sensors and actuators; in the energy industry, it can be used to monitor the voltage and current signals of power systems; in the field of test systems, it can be used to acquire and analyze test data.
  • Application Case: In an automotive manufacturing plant, the SCXI – 1104C is used to monitor the voltage signals of various sensors on the production line, such as temperature sensors, pressure sensors, and position sensors. By accurately acquiring and analyzing these signals, the system can timely detect the operating status of the equipment, predict potential failures, and improve the efficiency and quality of production.

NI SCXI-1104C

Competitive Product Comparison

Compared with some similar products, the – 1104C has the advantages of higher precision, wider input voltage range, and better noise rejection. For example, in some applications that require high – precision voltage measurement, the measurement accuracy of the SCXI – 1104C is higher than that of similar products, which can provide more accurate data support for the system. In addition, its wide input voltage range of ±60 VDC makes it more suitable for mid – level voltage measurement applications, while some similar products may have a narrower input voltage range.

Selection Suggestions

  • Compatibility: Make sure that the selected module is compatible with your existing equipment and software. The – 1104C requires NI – DAQ version 6.5.1 or higher and an appropriate application development environment.
  • Installation Environment: Consider the installation space and environmental conditions. The module has dimensions of 4.54 by 10.75 inches, and it should be installed in a clean, dry, and well – ventilated place1.
  • Budget: The – 1104C is a high – performance module, and its price is relatively high. You need to consider your budget when selecting to ensure that it meets your economic requirements.

Precautions

  • Safety Specifications: When using the SCXI – 1104C, make sure to follow the relevant safety regulations and use appropriate protective measures to avoid electric shock and other accidents.
  • Maintenance Recommendations: The module should be recalibrated at least once a year or whenever it is operated outside the specified temperature range of 0 to 50 °C. Regularly check the connection status of the module to ensure reliable operation1.

Shanxi Runsheng Import and Export Co., Ltd. is your reliable partner. We provide sales and technical support for NI SCXI – 1104C and other automation spare parts. Please visit our website www.rsautomationdirect.com or contact us, and we will be happy to serve you.
