Description
Product Parameters
Number of axes: 4 Pulse rate: Up to 1.25 MHz Resolution: Up to 32 bits Encoder support: Quadrature, PWM, SSI, and resolver Position compare: 4 Hardware limit switches: 4 Dimensions: 3U PXI form factor
Product Specifications
Motion modes: Point-to-point, linear and circular interpolation, electronic gearing, and CAM Advanced features: Trapezoidal and S-curve acceleration, jogging, contouring, and backlash compensation Communication: RS-485, Ethernet, and USB Software support: NI Motion Assistant, NI LabVIEW, and NI SoftMotion Module Operating temperature: 0°C to 55°C Power consumption: 5 W per axis
